Hytorc – ICE
A hydraulic bolting system delivering 159 to 7,263 Nm, with automatic release, a patented 3-axis swivel hose connection, and full HYTORC tensioning compatibility.
Additional Information
More Information
The Hytorc ICE is a hydraulic bolting system built on more than 50 years of HYTORC’s industrial bolting research, delivering torque from 159 to 7,263 Nm (117 to 5,360 ft-lbs). An automatic release system frees the tool from the bolt without manual intervention, cutting unplanned interruptions during the bolting process. It also works across the full HYTORC bolting ecosystem, including tensioning with the HYTORC Nut and HYTORC Washer.
Key Features
- Auto Release System — the tool releases itself automatically once locked onto a bolt, reducing unplanned interruptions.
- Total-Freedom Uniswivel — patented hose connection rotates freely across three axes, removing the positioning constraints of a fixed hydraulic hose.
- Reaction pawl mechanism rotates the nut a net 24° with every stroke, absorbing torsion rather than fighting it.
- Multi-use compatibility with the full HYTORC bolting system, including tensioning via the HYTORC Nut and HYTORC Washer.
- Interchangeable spanners and high-strength hex/Allen sockets suit standard and custom bolting applications.
Typical Applications
- Structural steel and flange bolting
- Oil and gas, petrochemical, and marine/shipboard maintenance
- Confined-access bolting requiring flexible hose positioning
- Multi-bolt flange work using HYTORC’s tensioning system
Hytorc ICE Specifications
| Spec | Detail |
|---|---|
| Torque Range | 159 – 7,263 Nm (117 – 5,360 ft-lbs) |
| Rotation Angle | 24° per stroke |
| Drive Sizes | 3/4″, 1″, 1-1/2″ (model dependent) |
| Hose Connection | Patented Total-Freedom Uniswivel (3-axis rotation) |
| Release | Automatic |
| Weight | Varies by model (ICE-1 through ICE-11) — confirm exact model with manufacturer |
