Diamond EP-1506L Electric Hydraulic Punch

An L-shaped puncher that can make holes in narrow spaces up to 30mm from the wall.

Categories: , Brand:

Specifications:

  • Maximum round hole diameter: φ15mm
  • Maximum oblong hole diameter: 11×16.5mm
  • Maximum plate thickness: SS400 equivalent: 6mm SUS304 equivalent: 5mm
  • Power supply/current: Single phase 100V 10.5A (1010W)
  • Body dimensions: (L)355×(W)180×(H)80mm
  • Weight: 7.7kg (including 2-core 2.5m cord)

Mechanism:

  • Double insulation
  • Position stopper

Standard Accessories:

  • Tool Set
  • Hydraulic Oil
  • Side Handle
  • Dedicated Resin Case
  • Standard Punch and Die: Ø11 Round Hole Set
